Electronics
Tektronix TBS1104 Digital Storage Oscilloscope
- 100 MHz Bandwidth Models
- 4-channel digital storage Up to 1 GS/s Sample Rate on All Channels
- 2.5k point Record Length on All Channels
- Advanced Triggers including Pulse Width Trigger and Line-selectable Video Trigger
Weller WR2 Rework Station, 2 Channel 120V
- Digital Self-Contained Multi-Channel Rework Station – 120V/300W
- 2 Independent tool channels with automatic tool recognition
- Self-contained vacuum and air
- Programmable temperatures
- Best for SMD soldering
Keithley 2000 Digital Multimeter
- 13 built-in measurement functions
- 2000 readings/second at 4-1/2 digits
- Optional scanner cards for multipoint measurements
- GPIB and RS-232 interfaces
- Fluke 8840/42 command set
- DC voltage from 0.1μ V to 1000V.
- AC (RMS) voltage from 0.1μV to 750V, 1000V peak.
Amprobe Tachometer Tach 10
- Measures rotational and surface speed
- User selectable units for contact measurement: RPM, m/min, ft/min, yd/min
- Non-contact measurement in RPM
- Digital display
Tektronix ADA400A Differential Preamplifier
- Active Differential Preamplifie
- 10μV/div Sensitivity
- Typically 100 dB CMRR DC to 10 kHz
- Integral Probe Power with TEKPROBE™ BN
Tektronix AFG1022 Arbitrary Function Generator
- Dual-channel, 25 MHz sine wave, and 12.5 MHz square/pulse wave provides a cost effective solution for basic education and other applications
- 125 MS/s sampling rate and 14-bit vertical resolution enable great signal fidelity
- 1 mVp-p to 10 Vp-p output amplitude over the whole frequency range
- 2 to 8,192-point length of memory for user-defined arbitrary waveforms
- 64-MByte internal non-volatile memory for arbitrary waveform storage
AMPROBE LUX METER LM 100 - Measure in Lux or Footcandles, Front Panel Switchable
- Measuring Range to 200000 Lux or 20000 Foot candles
- Silicon photodiode sensor and filter
- Data Hold to freeze reading on the digital display
Fluke 287 True RMS Digital Multimeter
- Auto- and manual-ranging, datalogging digital multimeter measures voltage, current, resistance, frequency, capacitance, temperature, conductance, pulse width, and duty cycle
- True RMS meter provides accurate readings when measuring linear or nonlinear loads where the current or voltage has a sinusoidal or nonsinusoidal waveform
- Datalogging features include minimum, maximum, and average, on-screen graphing, real-time clock, data hold, and data export to a computer
- Backlit LCD displays multiple measurements simultaneously and plots measurements on a single line to detect signal anomalies over time
Fluke 376 Clamp Meter
- iFlex® Flexible Current Probe expands the measurement range to 2500 A AC
- CAT IV 600 V, CAT III 1000 V
- True RMS AC voltage and current for accurate measurements on non-linear signals
- Min, max, average and Inrush recording to capture variations automatically
- Integrated low pass filter and state-of-the-art signal processing allows for use in noisy electrical environments while providing stable readings
- Proprietary Inrush measurement technology to filter out noise and capture motor starting current exactly as the circuit protection sees it
Gw Instek GPD-3303D DC Power Supply
- Three Independent, Isolated Output
- CH1/CH2 Output: 30V / 3A
- CH3 Voltage Selectable Output: ( +2.5V / 3.3V / 5.0V ) / 3A (Fixed)
- Series / Parallel Tracking Mode
- High Resolution Display 1mV / 1mA (For GPD-3303S)
- 100mV 10mA (For GPD-3303D)
- 4 Sets SAVE / RECALL panel setting
Hameg HM8118 LCR Measurement Bridge
- Basic Accuracy 0.05%
- Measurement functions L,C, R, |Z|, X, |Y|, G, B, D, Q, Θ, Δ, M, N
- Test frequencies from 20 Hz to 200 kHz
- Up to 12 measurements per second
- Parallel and Series Mode
- Binning and limits for parts sorting (optional)
- Internal programmable voltage and current bias
Gw INSTEK AFG2125 Arbitrary Function Generator Sine, Square, Triangular, Noise and Arbitrary Waveform
- 20MSa/s Sampling Rate, 10 bit Vertical Resolution and 4k Point Memory for Arbitrary Waveform
- 1% ~ 99% adjustable duty cycle for Square Waveform
- Waveform Parameter Setting Through Numeric Keypad Entry and Knob Selection
- Amplitude, DC Offset and Other Key Setting Information Shown on the 3.5” LCD Screen Simultaneously
- AM/FM/FSK Modulation, Sweep, and Frequency Counter Functions
KEITHLEY 2231A-30-3 triple channel DC power supply
- Type: AC/DC
- Mounting: Benchtop
- Other characteristics: triple-output, variable-output
- Output power: 195 W
- Output voltage: Min.: 0 V to Max.: 30 V
Keithley 2230-30-1 Programmable Triple Channel DC Power Supply
- Standard USB interface for automated testing
- Dual output model with two 30V/1.5A (45W) channels
- All channels are independently controlled and have isolated outputs for maximum flexibility
- Keypad entry allows fast, precise entry of output values
- All channels have remote sensing to ensure that programmed voltage is accurately applied to the load
- Two 30V channels can be combined either in series to double output voltage or in parallel to double output current
Tektronix 4050 digital multimeter
- 6.5 Digit Resolution
- Basic VDC Accuracy of up to 0.0024% (1 yr.)
- 100 mV to 1000 V Voltage Range, with up to 100 nV Resolution
- 100 μA to 10 A Current Range, with up to 100 pA Resolution
- 10 Ω to 1 GΩ Range, with up to 10 μΩ Resolution
- CAT I 1000 V, CAT II 600 V
Tektronix PA1000 single-phase Power Analyser
- High measurement accuracy of 0.05% (basic voltage/current accuracy)
- 1 MHz bandwidth / 1 MS/s sample rate for demanding test requirements
- Up to 600 Vrms voltage input
- Up to 20 Arms current input
- Dual internal current shunts maximize accuracy for high- and low-current measurements
Tektronix TBS1072B Digital Storage Oscilloscope
- 70 MHz bandwidth
- 2-channel
- Up to 1 GS/s sample rate on all channels
- 2.5k point record length on all channels
- Advanced triggers including pulse and line-selectable video triggers
- 34 automated measurements
- Dual window FFT, simultaneously monitors both the time and frequency domains
Dissolved Oxygen Meter DO-5509
- Range : 0 to 20 mg/L.
- ATC. Resolution : 0.1 mg/L
Yokogawa DL850E
- 8 Channel (8 more can be added)
- Continuous data recording
- Real-Time Measurement of Electrical Power
- Real-Time Mathematical Computations and Digital Filtering
- User defined computations
- Choose from 17 different types of input modules
- Continuous data recording for durability test and/or surveillance test , Max. 128-CH measurements
- Record measurements up to 200 days to internal hard disk
- Memory offers long duration measurement and two instantaneous zoom locations —2 GPoint memory
- Powerful trigger functions with unique features such as Dual-Capture & History Memory
- New power MATH trend calculations such as Active Power, Power Factor, Integrated Power and Harmonics
- GPS or IRIG time synchronization
- Flexible and swappable input modules with built-in signal conditioning
